Soil Mixers


C-Mac Soil Mixers

Mixing capacities available:

  • 1/2 cubic metre
  • 1 cubic metre
  • 2 cubic metre

Soil MixersLarger capacities and variations on request.

  • Mix any combination of potting material such as sand, soil, wood shavings, peat moss, sawdust, chemicals, fertilizer, etc.
  • Features ´ribbon flights´ for mixing batches in less than 3 minutes.

Soil MixersSpecifications

  • 1/2 cubic metre capacity – 4 kw, 3 phase motor – dimensions: 1m wide x 1m long x 1.55m high
  • 1 cubic metre capacity – 5.5 kw, 3 phase motor – dimensions: 1.3m wide x 1.3m long x 1.85m high
  • 2 cubic metre capacity – 15 kw, 3 phase motor – dimensions: 1.5m wide x 1.5m long x 2.2m high
  • Motor can be set Right Hand or Left Hand to suit the customer
  • Body manufactured from painted 3mm steel
  • Easy opening adjustable slide gate
  • Safety mesh over main opening with auto cut off when pivoted open
  • Tie down lugs for safe transport
  • Spindle easily removed if required
  • Water drainage holes on both sides for washing out unit

Options

  • Slippers for forklift tynes can be fitted
  • Hungry board (350mm) is 2mm galvanised steel adjustable 90 degrees to suit fill position.
  • Mesh exit grate
  • Pasteurisation mixer - inject steam into media while mixing
  • Replaceable liner available

C-Mac Soil Mixers C-Mac Soil Mixers C-Mac Soil Mixers

Heavy duty options available

  • ‘Ribbon flights’ (mixing vanes) from bisalloy or with ‘arc sprayed’ front surface to 65 rockwell for long term durability.
    ideal where using a crushed quartz mix.
  • Liner – 6mm bisalloy. Both body and sides are lined. ( 2 cubic metre only)

C-Mac Soil Mixers C-Mac Soil Mixers C-Mac Soil Mixers

See soil mixer ribbon action:
